Juget-Sinclair
Opus 55, 2024
Cathedral of the Sacred Heart
Gallery
823 Cathedral Place
Richmond, VA, US
83 Ranks - 4,336 Pipes - 7 Physical Divisions
Instrument ID: 66276 ● Builder ID: 7439 ● Location ID: 43647
⬆️ These are database IDs that may change. Don't use as academic reference.EXPLORE IMAGESVIEW STOPLISTSomething not quite correct?Suggest an Edit
IMAGES
Category:
Only show images in a specific category ☝️
Something missing or not quite correct?Add ImageorSuggest an Edit
STOPLISTS
Selected Item:
View additional stoplist entries if they exist ☝️
Click on a stop or division name for additional details if marked with 🛈.
| Grand-Orgue (I)🛈 | ||
| 16' | Montre🛈 | 58 |
| 16' | Bourdon | 58 |
| 8' | Montre🛈 | 58 |
| 8' | Salicional | 58 |
| 8' | Bourdon | 58 |
| 8' | Flûte Harmonique | 58 |
| 4' | Prestant | 58 |
| 4' | Flûte ouverte | 58 |
| 2 2⁄3' | Quinte | 58 |
| 2' | Doublette | 58 |
| 4/5-1 3/5' | Tiercelette | 58 |
| IV+II | Fourniture | 330 |
| III | Cymbale | 174 |
| V | Cornet🛈 | |
| 16' | Bombarde | 58 |
| 8' | Trompette | 58 |
| 4' | Clairon | 58 |
| 8' | Trompette en Chamade | 58 |
| 4-16' | Chamade | 58 |
| Carillon🛈 | ||
| Clochettes | ||
| Rossignol |
| Positif Expressif (II - Expressive)🛈 | ||
| 16' | Quintaton | 58 |
| 8' | Principal | 58 |
| 8' | Bourdon | 58 |
| 8' | Dulciane | 58 |
| 8' | Unda Maris | 46 |
| 4' | Prestant | 58 |
| 4' | Flûte à Cheminée | 58 |
| 2 2⁄3' | Nazard | 58 |
| 2' | Doublette | 58 |
| 2' | Flûte | 58 |
| 1 3⁄5' | Tierce | 58 |
| 1 1⁄3' | Larigot | 58 |
| 1' | Piccolo | 58 |
| V | Plein-Jeu | 290 |
| 16' | Cor Anglais | 58 |
| 8' | Cromorne | 58 |
| 8' | Trompette | 58 |
| Tremblant | ||
| 8' | Trompette en Chamade🛈 | |
| 4-16' | Chamade🛈 | |
| Carillon🛈 |
| Récit Expressif (III - Expressive)🛈 | ||
| 16' | Bourdon | 58 |
| 8' | Flûte Traversière | 58 |
| 8' | Cor de Nuit | 58 |
| 8' | Viole de Gambe | 58 |
| 8' | Voix Céleste | 46 |
| 4' | Salicional | 58 |
| 4' | Flûte Octaviante | 58 |
| 2 2⁄3' | Nazard Harmonique | 58 |
| 2' | Octavin | 58 |
| 1 3⁄5' | Tierce Harmonique | 58 |
| III-V | Plein-Jeu | 242 |
| 16' | Basson | 58 |
| 8' | Trompette Harmonique | 58 |
| 8' | Basson-Hautbois | 58 |
| 8' | Clarinette | 58 |
| 8' | Voix-Humaine | 58 |
| 4' | Clairon Harmonique | 58 |
| Tremblant | ||
| 8' | Trompette en Chamade🛈 | |
| 4-16' | Chamade🛈 |
| Pédale🛈 | ||
| 32' | Principal Basse🛈 | 12 |
| 16' | Contre-Basse | 30 |
| 16' | Montre | GO |
| 16' | Soubasse | 30 |
| 16' | Violon🛈 | 12 |
| 8' | Flûte | 30 |
| 8' | Bourdon | 30 |
| 8' | Violoncelle | 30 |
| 4' | Prestant | 30 |
| 4' | Flûte | 30 |
| 32' | Contre-Bombarde🛈 | 12 16' Bombarde |
| 16' | Bombarde | 30 |
| 16' | Trombone | 30 |
| 8' | Trompette | 30 |
| 4' | Clairon | 30 |
| 8' | Trompette en Chamade🛈 | GO |
| 4' | Clairon en Chamade🛈 |
| Chœur I🛈 | ||
| 16' | Bourdon | |
| 8' | Montre | |
| 8' | Flûte Traversière | |
| 8' | Bourdon | |
| 8' | Dulciane | |
| 4' | Prestant | |
| 2 2⁄3' | Quinte | |
| 2' | Doublette | |
| IV | Plein-Jeu |
| Chœur II Expressif (Expressive)🛈 | ||
| 8' | Cor de Nuit | |
| 8' | Viole de Gambe | |
| 8' | Voix Céleste | |
| 4' | Prestant | |
| 4' | Flûte Octaviante | |
| 2' | Octavin | |
| II-V | Plein-Jeu | |
| 16' | Basson | |
| 8' | Trompette | |
| 8' | Basson-Hautbois | |
| 4' | Clairon | |
| Tremblant🛈 |
| Chœur Pédale🛈 | ||
| 16' | Soubasse🛈 | |
| 8' | Basse Ouverte🛈 | |
| 8' | Bourdon🛈 | |
| 4' | Prestant🛈 | |
| 16' | Trombone |
Something missing or not quite correct?Add StoplistorSuggest an Edit
CONSOLES
Selected Item:
View additional console entries if they exist ☝️
Builder: Juget-Sinclair
Position: Keydesk Attached
Design: Traditional Without Cover
Pedalboard Type: Flat Radiating
Features:
3 Manuals (56 Notes)30 Note Pedal7 Divisions88 StopsMechanical (Balanced Tracker) Key ActionElectrical Stop Action✓ Sequencer✓ Combination Thumb Piston(s)✓ Combination Toe Piston(s)✓ Coupler Thumb Piston(s)✓ Coupler Toe Piston(s)Stop Layout: Drawknobs in Horizontal Rows on Curved Jambs
Expression Type: Balanced Expression Shoes/Pedals (Details Unknown)
Combination Action: Adjustable Combination Pistons
Control System: Unknown or N/A
Something missing or not quite correct?Add ConsoleorSuggest an Edit
DETAILS
Switch between notes, documents, and blowers ☝️
This instrument is: Extant and Playable in this location
William Tan on August 3rd, 2024:
Completed July 2024. Blessing September 14th by Bishop Knestout, two dedicatory recitals October 30th, 2024 by Olivier Latry, Vespers October 29th with Olivier Latry.
Completed July 2024. Blessing September 14th by Bishop Knestout, two dedicatory recitals October 30th, 2024 by Olivier Latry, Vespers October 29th with Olivier Latry.
Paul R. Marchesano on April 16th, 2024:
To be completed 2024
Webpage Links: Builder's Page
Related Instrument Entries: Juget-Sinclair (Opus 54, 2021)
Something missing or not quite correct?Add NoteorAdd WebpageorAdd Cross ReferenceorSuggest an Edit
