Glatter-Götz / Rosales
2024
Trinity Episcopal Church
Broadway at Wall Street
New York City: Manhattan, NY, US
138 Ranks - 8,041 Pipes - 11 Physical Divisions
Instrument ID: 71167 ● Builder ID: 7356 ● Location ID: 7537
⬆️ These are database IDs that may change. Don't use as academic reference.EXPLORE IMAGESVIEW STOPLISTSomething not quite correct?Suggest an Edit
Plenum Organ Company
🤝 Instrument entries in New York sponsored by:
We are grateful for the generous support of our sponsors, who make it possible for us to continue our mission of preserving and promoting the rich history of pipe organs across the globe.
IMAGES
Category:
Only show images in a specific category ☝️
Something missing or not quite correct?Add ImageorSuggest an Edit
STOPLISTS
Selected Item:
View additional stoplist entries if they exist ☝️
Click on a stop or division name for additional details if marked with 🛈.
| Great🛈 |
| Chaire🛈 |
| Swell (Expressive)🛈 |
| Choir (Expressive)🛈 |
| Solo (Expressive)🛈 |
| Pedal🛈 |
| Chancel Great (Expressive)🛈 | ||
| 16' | Bourdon | 73 |
| 8' | Diapason🛈 | 61 |
| 8' | Chimney Flute | Spire Flute |
| 8' | Salicional | SW |
| 8' | Celeste | SW |
| 4' | Octave🛈 | 61 |
| 4' | Spire Flute | 61 |
| 2' | Fifteenth | 61 |
| IV | Mixture | 244 |
| 8' | Bell Clarinet | SW |
| Tremolo | ||
| Chancel Great Unison Off |
| Chancel Positive🛈 | ||
| 8' | Principal🛈 | 61 |
| 8' | Gedeckt | 61 |
| 4' | Hohlflöte | 61 |
| 2' | Doublet | 61 |
| Chancel Positive Unison Off |
| Chancel Swell (Expressive)🛈 | ||
| 8' | Geigen Principal | 61 |
| 8' | Harmonic Flute | 49 1-12 from Pedal |
| 8' | Salicional | 61 |
| 8' | Celeste | 61 |
| 4' | Flute | 61 |
| 2 2⁄3' | Nasard | 61 |
| 2' | Piccolo | 61 |
| 1 3⁄5' | Tierce | 61 |
| 16' | Contra Oboe | 73 |
| 8' | Trompette | 61 |
| 8' | Oboe | Contra Oboe |
| Tremolo | ||
| 16' | Chancel Swell to Chancel Swell | |
| Chancel Swell Unison Off | ||
| 4' | Chancel Swell to Chancel Swell |
| Chancel Solo (Expressive)🛈 | ||
| 8' | Aeoline | 61 |
| 8' | Unda Maris | 61 |
| 8' | Vox Humana | 61 |
| Tremolo | ||
| 16' | Trombone | 61 |
| 8' | Trumpet | 61 |
| 4' | Clarion | 61 |
| 16' | Chancel Solo to Chancel Solo | |
| Chancel Solo Unison Off | ||
| 4' | Chancel Solo to Chancel Solo |
| Chancel Pedal🛈 | ||
| 16' | Open Bass | 44 |
| 16' | Bourdon | GT |
| 8' | Octave Bass | Open Bass |
| 8' | Diapason | GT |
| 8' | Chimney Flute | GT |
| 8' | Salicional | SW |
| 4' | Octave | GT |
| 4' | Chimney Flute | GT |
| 16' | Trombone | SO |
| 16' | Contra Oboe | SW |
| 8' | Trumpet | SO |
| 4' | Clarion | SO |
Stoplist developed by Jonathan Ambrosino. Chancel organ installed and playing with a temporary two-manual console, with touchscreen stop controls, as well as pistons. Gallery Organ completion date expected early 2025.
Originally Written/Published: 2024
Something missing or not quite correct?Add StoplistorSuggest an Edit
CONSOLES
No console details are available. If you have information, please consider sharing it with us.
Something missing?Add Console
DETAILS
Switch between notes, documents, and blowers ☝️
This instrument is: Extant and Playable in this location
Jim Stettner on August 3rd, 2025:
This entry represents the installation of a new organ. Identified through online information from Facebook posts by Manuel Rosales and from the Trinity Church website. A question was raised about whether or not the new instrument contained any retained pipework from the previous Aeolian-Skinner instrument. I initiated contact with Manuel Rosales who kindly responded via Facebook Messenger the evening of August 2, 2025. This was his response: "All Gallery pipes are new and custom made in Portugal, Germany, Spain and manual reeds in England. The 32’ Trombone (unit) and other pedal reeds were made by A.R. Schopps. All Chancel pipes are new and custom made in Germany and all reeds by A.R. Schopps and Sons. All windchests, bellows and both consoles were made by GGO in Germany. There are no used or refurbished pipes or mechanisms." The only items retained were the historic gallery 1846 Erben case and the chancel 1901 Hook & Hastings cases.
This entry represents the installation of a new organ. Identified through online information from Facebook posts by Manuel Rosales and from the Trinity Church website. A question was raised about whether or not the new instrument contained any retained pipework from the previous Aeolian-Skinner instrument. I initiated contact with Manuel Rosales who kindly responded via Facebook Messenger the evening of August 2, 2025. This was his response: "All Gallery pipes are new and custom made in Portugal, Germany, Spain and manual reeds in England. The 32’ Trombone (unit) and other pedal reeds were made by A.R. Schopps. All Chancel pipes are new and custom made in Germany and all reeds by A.R. Schopps and Sons. All windchests, bellows and both consoles were made by GGO in Germany. There are no used or refurbished pipes or mechanisms." The only items retained were the historic gallery 1846 Erben case and the chancel 1901 Hook & Hastings cases.
