Schantz Organ Co.
2024
First German Lutheran Church
1033 S. Eighth St.
Manitowoc, WI, US
24 Ranks - 1,586 Pipes - 3 Physical Divisions
Instrument ID: 71503 ● Builder ID: 7079 ● Location ID: 61630
⬆️ These are database IDs that may change. Don't use as academic reference.EXPLORE IMAGESVIEW STOPLISTSomething not quite correct?Suggest an Edit
IMAGES
Category:
Only show images in a specific category ☝️
Something missing or not quite correct?Add ImageorSuggest an Edit
STOPLISTS
Selected Item:
View additional stoplist entries if they exist ☝️
Click on a stop or division name for additional details if marked with 🛈.
| GREAT🛈 | ||
| 8' | Open Diapason | 73 |
| 8' | Doppel Flute | 73 |
| 8' | Melodia | 73 |
| 8' | Dulciana | 73 |
| 4' | Principal | 73 |
| 4' | Flute d'Amour | 73 |
| 2 2⁄3' | Twelfth | 61 |
| 2' | Fifteenth | from Mixture |
| III | Mixture | 183 |
| 8' | Trumpet | 73 |
| Tremolo | ||
| Chimes | 21 | |
| 16' | GREAT to GREAT | |
| GREAT Unison Off | ||
| 4' | GREAT to GREAT | |
| 16' | SWELL to GREAT | |
| 8' | SWELL to GREAT | |
| 4' | SWELL to GREAT |
| SWELL (Expressive)🛈 | ||
| 16' | Lieblich Gedeckt | 73 |
| 8' | Violin Diapason | 73 |
| 8' | Stopped Diapason | 12 Lieblich Gedeckt |
| 8' | Salicional | 73 |
| 8' | Voix Celeste | 61 tc |
| 4' | Principal | 61 |
| 4' | Flute Harmonic | 61 |
| 2 2⁄3' | Nasard | 61 |
| 2' | Piccolo | 61 |
| 1 3⁄5' | Tierce | 61 |
| 8' | Cornopean | 61 |
| 8' | Oboe | 61 |
| Tremolo | ||
| 16' | SWELL to SWELL | |
| SWELL Unison Off | ||
| 4' | SWELL to SWELL |
| PEDAL🛈 | ||
| 32' | Resultant | |
| 16' | Open Diapason | 32 1-12 wood |
| 16' | Bourdon | 32 |
| 16' | Lieblich Gedeckt | Swell |
| 8' | Diapason | 12 |
| 8' | Bourdon | 12 |
| 8' | Flute | Swell |
| 4' | Fifteenth | 12 |
| 16' | Double Trumpet | 12 Great |
| 8' | Trumpet | Great |
| 4' | Clarion | Great |
| 8' | GREAT to PEDAL | |
| 4' | GREAT to PEDAL | |
| 8' | SWELL to PEDAL | |
| 4' | SWELL to PEDAL |
Something missing or not quite correct?Add StoplistorSuggest an Edit
CONSOLES
Selected Item:
View additional console entries if they exist ☝️
Builder: Schantz Organ Co.
Position: Console in Fixed Position, Left
Design: Traditional With Roll Top
Pedalboard Type: Concave Radiating (Meeting AGO Standards)
Features:
2 Manuals (61 Notes)32 Note Pedal3 Divisions22 Stops32 RegistersElectrical Key ActionElectrical Stop Action✓ Crescendo✓ Transposer✓ Sequencer✓ Record/Playback✓ Combination Thumb Piston(s)✓ Combination Toe Piston(s)✓ Coupler Thumb Piston(s)✓ Coupler Toe Piston(s)✓ Sforzando Thumb Piston(s)✓ Sforzando Toe Piston(s)Stop Layout: Stop Keys Above Top Manual
Expression Type: Balanced Expression Shoes/Pedals (Meeting AGO Standards)
Combination Action: Computerized/Digital
Control System: Peterson
Something missing or not quite correct?Add ConsoleorSuggest an Edit
DETAILS
Switch between notes, documents, and blowers ☝️
This instrument is: Extant and Playable in this location
Jeff Scofield on May 11th, 2024:
Originally installed in 1919 as 2/18 Tellers-Kent Op. 164; additions in 1978 by Christopher Feiereisen; rebuild and tonal changes by Schantz in 2024.
Originally installed in 1919 as 2/18 Tellers-Kent Op. 164; additions in 1978 by Christopher Feiereisen; rebuild and tonal changes by Schantz in 2024.
